Industrial Single-Tank & Special Cleaners
LENJEX Tilt-Rocking Industrial Ultrasonic Cleaner
Rocking motion and ultrasonic cavitation in one batch cleaner
The system adds adjustable horizontal rocking to ultrasonic cleaning so parts remain in motion during the cycle. The combined action accelerates oil removal and improves exposure around complex geometry and blind holes.
Batch industrial cleaning of automotive parts, stampings, molds, hydraulic parts, bearings and workpieces that benefit from motion during the ultrasonic cycle.
Review the construction, controls and process options available for this equipment.
01
LENJEX Tilt-Rocking Series
Product Features
01
Dual-action rocking and ultrasound
Adjustable horizontal motion keeps parts moving for more uniform cleaning.
02
Three capacity options
96, 192 and 320 L versions cover 36 to 100 transducers.
03
Industrial 28 KHz power
The transducer system is intended for sustained batch industrial cleaning.
04
2.5 mm SUS304 tank
Five-sided stainless construction supports corrosion resistance and service life.
05
Wide heating and timing ranges
Temperature is adjustable from ambient to 100 degrees C and time from 1 to 166 minutes.
Parameter
Small
Medium
Large
Capacity
96 L
192 L
320 L
Transducers
36 pcs
64 pcs
100 pcs
Ultrasonic power
2160 W
3840 W
6000 W
Tank inner size
600 x 400 x 400 mm
800 x 600 x 400 mm
1000 x 800 x 400 mm
Overall size
1250 x 600 x 930 mm
1450 x 800 x 930 mm
1650 x 1000 x 930 mm
Heating power
4.5 kW
6 kW
9 kW
Temperature range
Ambient-100 degrees C
Ambient-100 degrees C
Ambient-100 degrees C
Timer range
1-166 min
1-166 min
1-166 min
Heating supply is AC 380 V / 50 Hz. Each size uses a 2.5 mm SUS304 tank and can be paired with the available accessories.
Applications
Typical applications
Review common workpieces, contamination types and process uses for this equipment.
01
Applicable Industries
For automotive, hardware, mold and hydraulic-component cleaning.
01
Automotive parts
02
Hardware stampings
03
Molds
04
Hydraulic components
05
Bearings
06
Pre-plating treatment
07
Post-heat-treatment cleaning
Configuration Options
Configure the system for your process
Tank dimensions, utilities, automation and process settings are finalized around the application requirements.
96, 192 or 320 L tank
36, 64 or 100 transducers
Rocking speed
Ambient-100 degrees C temperature
1-166 minute timer
Basket, lid, generator rack and filter accessories
Model range
Small / Medium / Large sizes
Ultrasonic frequency
28 KHz
Capacity or line basis
96 / 192 / 320 L
Ultrasonic power
2160 / 3840 / 6000 W
Construction
2.5 mm SUS304 on five tank sides
Product Questions
Before selecting this equipment
Yes. Tank dimensions, basket loading, ultrasonic frequency, power, heating, filtration, handling and controls are reviewed for the part and process. Batch industrial cleaning of automotive parts, stampings, molds, hydraulic parts, bearings and workpieces that benefit from motion during the ultrasonic cycle.
Send part drawings or dimensions, material, maximum weight, contamination, required cleanliness, parts per load, daily output and available utilities.
Yes. Representative parts can be used to evaluate chemistry, cycle conditions, loading and inspection criteria before the final configuration is confirmed.
